Gas Welding and cutting needs a flexible and rugged hose pipe for the flow of air-oxygen and a fuel gas like acetylene. We offer an alternative for a traditional rubber hose which is a flame retardant, oil resistant PVC Welding Hose. PVC oxygen hose is made from High Temp proof Plasticizers and blended with Flame Retardant additives with a desired dose of Nitrile Rubber.
Construction:
Tube: PVC material
Reinforce: high tensile polyester or cotton braid
Cover: PVC, red, black,blue.
Applications:
Such welding hose widely serves in welding machine, architeture and lacquer factory
Characteristic:
●High tensile polyester reinforced
●Work under high pressure 300psi
●Strong peeling adhesion between fire and PVC
●light, flexible, non-kink, non-twist, UV, ozone and weather proof
●Can be used for jackhammer hoe
Temperature: -10℃(-50℉) to 65℃(+150℉)
5 Layer Pvc Welding Hose | ||||||||
I.D | O.D | W.P | B.P | Length | Weight | |||
inch | mm | mm | psi | bar | psi | bar | m/roll | Kg/m |
1/4" | 6.5 | 12 | 450 | 30 | 1800 | 120 | 50/100 | 110 |
5/16" | 8 | 14 | 450 | 30 | 1800 | 120 | 50/100 | 135 |
3/8" | 10 | 16 | 450 | 30 | 1800 | 120 | 50/100 | 160 |
1/2" | 13 | 20 | 300 | 20 | 1800 | 120 | 50/100 | 240 |
5/8" | 16 | 24 | 300 | 20 | 900 | 60 | 50/100 | 330 |
3/4" | 19 | 28 | 300 | 20 | 900 | 60 | 50/100 | 450 |
1" | 25 | 34 | 300 | 20 | 900 | 60 | 50/100 | 560 |
1-1/4 | 32 | 45 | 300 | 20 | 900 | 60 | 50/100 | 940 |
